SKU: 504420

Thompson 4200 Mixer Mincer

Incorporating all of the strength and features of the 4000 Series the Thompson 4200 Mixer Mincer has been designed and constructed to withstand the higher forces and demands with colder temperature blocks.


The Thompson 4200 Frozen Mixer Mincer is available and is constructed to process hard, frozen product.


The construction of the heavy duty reinforced bowl and paddles have been structurally engineered to process tempered blocks size of 150 x 150 x 400mm at -1°C. Frozen blocks of meat 50mm cube/flaked at -10°C through a minimum hole plate of 8mm diameter.


The frozen feedscrew is uniquely designed with an infeed bellow in the channel to the barrel.


This bellow, incorporated with the specific flight design to the feedscrew, cuts the product into small pieces and feeds to the cutting head.


Powerful motors with high torque transmissions achieve high production rates on coarse mince with a hard, dry product.

arrow_forward Submit An Enquiry

Please fill out this form and we will be in touch

Product Enquiry
Viking Hire


link Copy link to this section
Cutting Size #56
Hopper Size 300L
Mix Capacity 200kg
Primary Cut - 13mm 4,000kg/hr
Secondary Cut - 4mm 2,000kg/hr
Bowl Diameter x Length 594 x 895mm
Floor Space 1840 x 904mm
Loading Height 1722mm
Mix Motor 3HP 2.2kW
Grinding Motor 20HP 15kW
2 Speed Mincing Standard
Power 415V 40A
Power Requirement To be fitted with a “D” curve motor start circuit breaker


link Copy link to this section
Thompson 4200 Mixer Mincer & 200lt Bin Hoist



Book Hire Now

link Copy link to this section
This machine is available for hire. Fill in your details and our team will be in contact with you to arrange your hire.
Product Book Hire

More Videos

link Copy link to this section

Bin Hoist & 200L Euro Bins to Suit
